Introducing Laowa Proteus – with the optimized level of optical capability to support professional anamorphic productions. It is a series of anamorphic lenses with a constant 2X squeeze ratio. Built with reliable anamorphic glass and robust composition, the Proteus is a modern piece of art to deliver a vintage anamorphic look and unique character.
Key Features
- Patented anamorphic design
- 2X constant squeeze ratio
- T2 Large Aperture
- Outstanding sharpness
- Close focusing distance
- Pleasant oval bokeh
- Amber, blue & silver flare colors
- Low Focus-breathing
- User-friendly cine housing
- Full-frame coverage with 1.4X extender
Patented Anamorphic Design
Laowa Proteus is comprised of anamorphic and spherical blocks, delivering modern image sharpness and vintage anamorphic characteristics including elliptical bokeh and signature flares at the same time.
Both anamorphic and spherical blocks are fixed, a front variable spherical glass is added to achieve focus. Similar optical design is used in Vantage Hawks, Cooke Anamorphic and Atlas Orion.
Constant 2X Squeeze Ratio
With a 2X squeeze ratio, you will have a 2.66:1 on a 4:3 sensor and a 2.4:1 on a 6:5 sensor after de- squeeze. It provides room for cropping to a golden 2.39:1 aspect ratio.
Image after de-squeeze with 6:5 format
Constant 2X Squeeze Ratio
The 2X squeeze ratio yields an ultra-widescreen cinematic look which is wildly desired by the film industry.
Large Aperture
- Featuring a T2 aperture, the fast aperture supports filmmakers to shoot in low-light conditions.
- It also creates a shallow depth of field with waterfall-like focus roll- off.
Outstanding Sharpness
Impressive sharpness and contrast at wide-open, Laowa Proteus Series satisfies demanding film production requirements.
Close Focusing Distance
- Able to focus at a min. distance of 55cm (21.6 inches) away from the object.
- Creating sharp close-up cinematic scenes at ease.
Pleasant Bokeh
- Elliptical bokeh is produced in the out-of-focus area, which is a signature anamorphic character for the strong cinematic look.
- The bokeh in 2X squeeze ratio is prominently thinner and longer.
Flare Colors
- Provides classic sci-fi blue, warm and elegant amber and neutral silver flare color options.
- The flare of silver version will change colors according to the light source.
- DPs can choose the flare colors to set the right tone for the vibe of the scenes.
- Flare colors are indicated on each lens body under the focal length.
Low Focus Breathing
Both changes in the angle of view and framing are kept at minimum when adjusting the focus.
User-friendly Cine Housing
- 0.8 mod gear
- Back focus adjustment
- available for metric or imperial scales
- Ø 105mm filter thread for more light entering
- Ø 114mm outer diameter
- Unified gear position
- 300° focus throw
- lens support
Sensor Coverage
Having a s35+ sensor coverage, Laowa Proteus supports the Alexa 35 sensor in 2.39:1 ratio and Red V-Raptor sensor in 7K 6:5 ANA.
Proteus 45mm on Alexa 35 sensor 3.3K 6:5
Sensor Coverage
With 1.4X full frame adaptor, Proteus can cover full frame sensor with astonishing sharpness and image quality.
Proteus 35mm on Z Cam Open Gate
